ASME SA192 / ASTM A192 Carbon Steel Boiler Tubes Manufacturer In India

ASTM A192 Carbon Steel Boiler Tube Manufacturers

ASTM A192 Carbon Steel Boiler Tubes Updated Price List in Mumbai(Maharashtra), India

Vishal Tube are Stocking extensive range of ASTM A192 Boiler Tubes Manufacturer In India, Professional Dealer and Distributor of ASTM A192 Boiler Tubes, ASTM A192 Boiler Tubes Stockholder, Check Updated Price list 2018-2019 of ORPIC approved Supplier of ASTM A192/ASME SA192 Seamless Medium Carbon Steel Boiler and Superheater Tubes in Pune, Banglore(Karnataka), Kakinada, Kerala, MP(Madhya Pradesh) and India. ASME SA192 Seamless Steel Boiler Tube Manufacturer In Mumbai(Maharashtra).

We are Supplier and Exporter of ASME SA192 Carbon Steel Steam Boiler Tubes, India’s Largest Stockholder of ASTM A192 Fluid Seamless Steel Boiler Tube offer best Price Per Ton in Dubai, Thailand, Iran, India. We offers quality ASME SA192 / ASTM A192 Boiler Tube and Tubing are available in various grades and specifications. These ASTM A192 Heat Exchanger Tubes are made from the finest quality Seamless steel and are available in different Size, shapes, dimensions, thickness, grades and hardness. Our ranges of ASTM A192 Condensor Boiler Tubes are widely appreciated for their optimum.

Send Enquiry



ASTM A192 Seamless Carbon Steel Boiler Tubes Specification

Standard	:	ASME SA 192 / ASTM A192
Size Range	:	O.D.:6.0~114.0; W.T.:1~15; L: max 12000
Outer Dimensions	:	6.0mm – 114.0mm
Wall Thickness	:	1mm – 15 mm
Length	:	max 27000mm



ASTM A192 Carbon Steel Boiler Tubes Manufacturer

Name:
ASTM A192 Seamless Carbon Steel Boiler Tubes

Size (mm):
O.D.: 6.0~114.0; W.T.: 1~15; L: max 12000

Description：

► Standards: ASTM A192 (ASME SA192)
► Applications: A wide range scope: heat exchangers, condensers, heat transfer equipment, similar pipes and as superheater tubes for high pressure settings.
► Grade: A 192

ASTM A192 Boiler Tubes Packaging & Shipping

ASTM A192 Boiler Tube in Vishal Tube, Mumbai

ASTM A192 Boiler Tube, Mumbai

ASTM A192 Boiler Tubes are loose or in bundles tightened with Iron Strips.
Special packings: Metal or Wooden Cases, Pallets etc.

• Packed in wooden crates, wrapped in plastic, and suitably protected for sea-worthly delivery or as requested.
• Both ends of each crate will indicate the order no., heat no., dimensions, weight and bundles.

Chemical Composition

C, %	Mn, %	Si, %	P, %	S, %
0.06-0.18	0.27-0.63	0.25 max	0.035 max	0.035 max

Mechanical Properties

Tensile Strength , MPa	Yield Strength , MPa	Elongation, %	Hardness, HB, WT≥5.1mm	Hardness, HRB, WT＜5.1mm
325 min	180 min	35 min	137 max	77 max

Outside Diameter & Tolerance

Hot rolled	Outside Diameter, mm	Tolerance, mm
	OD≤101.6	+0.4/-0.8
	101.6＜OD≤177.8	+0.4/-1.2
Cold Drawn	Outside Diameter, mm	Tolerance, mm
	OD＜25.4	±0.10
	25.4≤OD≤38.1	±0.15
	38.1＜OD＜50.8	±0.20
	50.8≤OD＜63.5	±0.25
	63.5≤OD＜76.2	±0.30
	76.2≤OD≤101.6	±0.38
	101.6＜OD≤177.8	+0.38/-0.64

Wall thickness & Tolerance

Hot rolled	Outside Diameter, mm	Tolerance, %
	OD≤101.6, WT≤2.4	+40/-0
	OD≤101.6, 2.4＜WT≤3.8	+35/-0
	OD≤101.6, 3.8＜WT≤4.6	+33/-0
	OD≤101.6, WT>4.6	+28/-0
	OD>101.6, 2.4＜WT≤3.8	+35/-0
	OD>101.6, 3.8＜WT≤4.6	+33/-0
	OD>101.6, WT>4.6	+28/-0
Cold Drawn	Outside Diameter, mm	Tolerance, %
	OD≤38.1	+20/-0
	OD>38.1	+22/-0



Send Enquiry



Send Enquiry

OD (mm)

Wall Thickness (mm)

2

2.5

3

3.5

4

4.5

5

6

6.5-7

7.5-8

8.5-9

9.5-10

11

12

Φ25-Φ28

●

●

●

●

●

●

Φ32

●

●

●

●

●

●

Φ34-Φ36

●

●

●

●

●

●

Φ38

●

●

●

●

●

●

Φ40

●

●

●

●

●

Φ42

●

●

●

●

●

Φ45

●

●

●

●

●

●

Φ48-Φ60

●

●

●

●

●

●

●

Φ63.5

●

●

●

●

●

●

●

Φ68-Φ73

●

●

●

●

●

●

Φ76

●

●

●

●

●

●

●

●

●

●

Φ80

●

●

●

●

●

●

●

●

●

●

Φ83

●

●

●

●

●

●

●

●

●

●

Φ89

●

●

●

●

●

●

●

●

●

●

Φ95

●

●

●

●

●

●

●

●

●

●

Φ102

●

●

●

●

●

●

●

●

●

●

Φ108

●

●

●

●

●

●

●

●

●

●

Φ114

●

●

●

●

●

●

●

●

●

Φ121

●

●

●

●

●

●

●

●

●

Φ127

●

●

●

●

●

●

●

●

●

Φ133

●

●

●

●

●

●

●

●

●

Φ140

●

●

●

●

●

●

●

●

Φ146

●

●

●

●

●

●

●

●

Φ152

●

●

●

●

●

●

●

●

Φ159

●

●

●

●

●

●

●

●

Φ168

●

●

●

●

●

●

●

●
